Ace EV 1000

TATA Ace EV 1000 is India's 1st and only Electric Mini Truck with a 1000 kg payload, powered by the EVOGEN. Ace EV 1000 offers a comprehensive solution for dedicated on-time delivery with zero-emission solutions for Last Mile Urban Cargo Transportation. The Ace EV 1000 features a 161*km range on a single charge and has a 7* year battery warranty

2120 kg

GWV

NA

Fuel Tank Capacity

NA

Engine

Download Brochure

Earn More with Better Mileage and Better Pickup

High Pickup of 130 Nm and power of 36 HP for faster trips

161* km ARAI certified range in single charge
Regenerative braking while braking, coastings & downhill
Fast charging in 105* minutes - enabling multishift operations

Clutchless Operations & single speed gear box for a fatigue free driving
Low effort Steering Wheel
Fleetedge solution for real time vehicle tracking and analysis
Ease of charging at Home through 16 Amp socket
Digital instrument cluster
Seats with Head Rest & Ample leg room

Higher Payload of 1000 kg
High Loadability due to Front & rear leaf spring suspension
Heavy Duty Chassis
Bigger 13" tyre for higher loadability

Fewer moving parts leading to lower maintenance and higher uptime
Lower cost of operations leading to savings in running cost
Liquid cooled Battery Cooling Technology for enhanced battery safety & its life

High Loadability for higher revenues
161* km of range in single charge leading to savings in running cost
7* year HV Battery warranty with enhanced battery life

Applications

Parcel & Courier

Gas Cylinders

E-Commerce

Municipal application

Fisheries

FMCG

Water bottles

Engine

Type	Lithium Ion Iron phosphate (LFP) Battery
Power	27 kW (36 HP) @ 2000 rpm
Torque	130 Nm @ 2000 rpm
Gradeability	20%

Clutch and Transmission

Gear Box Type	Single speed Gearbox
Steering	Mechanical, Variable Ratio
Max Speed	60 kmph

Brakes

Brakes	Dual circuit Hydraulic brakes
Regenerative Brake	Yes
Suspension Front	Rigid Axle with Parabolic Leaf Spring
Suspension Rear	Live Axle with Semi-elliptical Leaf Spring

Wheels and Tyres

Tyres	155 R13 LT 8PR Radial (Tubeless Type)

Vehicle Dimensions (mm)

Length	3800 mm
Width	1500 mm
Height	1840 mm
Wheelbase	2100 mm
Front Track	1310
Rear Track	1343
Ground Clearance	160 mm
Min TCR	4300 mm

Weight (kg)

GVW	2120 kg
Payload	1000 kg

Battery

Battery Chemistry	LFP (Lithium-Iron Phosphate)
Battery Energy (kWh)	21.3
IP Rating	67
Certified Range	161 km in single charge
Slow Charging time	7 hrs (10% to 100%)
Fast Charging time	105 min (10% to 80%)
