Small Commercial Vehicles
-
Tata Ace Gold CNG
The trusted Tata Ace range has empowered 24 Lakhs + entrepreneurs while helping individuals achieve their success goals. One of India’s most desired Small Commercial Vehicles.
1630
GVW
70L (2 X 35L) | 12KG (2 X 6 Kg)
Fuel Tank Capacity
2 cylinder 694CC
Engine
Step into the future of last-mile delivery with the Ace Pro
Earn More with Better Mileage and Better Pickup
- Enhanced Focus Range with 5X Improved Illumination Intensity for safe driving at night and early mornings
- Improved Steering Box with 35% Reduced Steering Effort
- Ergonomic Flat Seats with Head Rest and Extra Rear Ward Travel for maximum comfort while driving.
- Better driving experience with Pendular APM module
- A 2-cylinder 694cc gas injection engine for better Power & Pick up
- Max Power of 19.4 kW
- Max Torque of 51 Nm
- Fuel Efficient 2 cylinder engine with Gear shift advisor gives better mileage for extra trips.
- 2520 mm (8.2 feet) long load body
- Leaf spring suspension for more loading
Engine
| Type | WATER COOLED;MULTIPOINT GAS INJECTION DEDICATED CNG ENGINE |
| Power | 19.40kW |
| Torque | 51 N-m @ 2500 RPM |
| Gradeability | 35% |
Clutch and Transmission
| Gear Box Type | GBS 65-5/5.6 |
| Steering | Mechanical, variable ratio (23.1 to 28.9:1), 380 mm Dia |
| Max Speed | 70 kmph |
Brakes
| Brakes | Front - Disc brakes; Rear - Drum brakes 200mm dia. x 30mm; LCRV provided for Rear brakes only |
| Suspension Front | Parabolic leaf spring |
| Suspension Rear | Semi - Elliptical leaf spring |
Wheels and Tyres
| Tyres | 145R12 LT 8PR RADIAL TUBELESS TYRES |
Vehicle Dimensions (mm)
| Length | 4075 |
| Width | 1500 |
| Height | 1850 |
| Wheelbase | 2250 |
| Ground Clearance | 160 |
| Min TCR | 4625 |
Weight (kg)
| GVW | 1630 |
| Payload | 640 |
Performance
| Gradeability | 35% |
Seating & Warranty
| Seats | D+1 |
| Warranty | 2 Years / 72000 Kms |
