Tata Ace Gold Petrol

Ace Gold Petrol BS6 Phase 2 is loaded with a peppy 2 cylinder 694 CC engine delivering 22.1 kW (30HP) max power and 55 Nm max torque. The vehicle comes with a superior Direct Drive gearbox delivering higher Fuel Efficiency, higher drivability experience and higher comfort.

1740

GWV

26L

Fuel Tank Capacity

694 cc

Engine

Download Brochure

Earn More with Better Mileage and Better Pickup

Bigger Headlamp with 5X Improved illumination intensity
Improved Focus Range for safe night and early morning driving

New Direct Drive Gear Box with improved drivability, improved fuel efficiency and low NVH
New steering box with 35% reduced steering effort

Flat seat for in Cabin driver resting.
Ergonomic seats with Head Rest and extra rear ward travel for ergonomic driving.
Pendular APM module for better driving experience

A 2 cylinder 694cc E20 Fuel compliant engine offering higher Power & Pick up
Max Power of 22.1 kW
Max Torque of 55 Nm

New Direct Drive Gear Box offering upto 5% higher Mileage

Low maintenance Engine
Long Service Intervals
3 year / 1 00 000 km (whichever is earlier)

Applications

Parcel & Courier

Gas Cylinders

E-Commerce

Municipal application

Fisheries

FMCG

Milk

Engine

Type	694cc MPFI BS-VI RDE, 4 Stroke Water cooled
Power	22.1 kW (30 HP) @ 4000 RPM
Torque	55 Nm @ 2500-3000 RPM
Gradeability	37%

Clutch and Transmission

Gear Box Type	GBS 65- 5/6.31
Steering	mechanical variable ratio (27.9 to 30.4) Variable, 380 mm Dia
Max Speed	65 kmph

Brakes

Brakes	Front - Disc brakes; Rear - Drum brakes
Regenerative Brake	-
Suspension Front	Rigid Axle with Parabolic Leaf Spring
Suspension Rear	Live Axle with Semi- Elliptical Leaf Spring
